| Model Number | Maximum Operating Pressure (bar) | For Use With Torque Wrenches | Reservoir Capacity (cm3) | Usable Oil Capacity (litres) | Maximum Flow at Rated Pressure | Output Flow Rate at 7 bar (l/min) | Output Flow Rate at 50 bar (l/min) | Output Flow Rate at 350 bar (l/min) | Output Flow Rate at 700 bar (l/min) | Motor Size (hp) | Motor Hertz | Motor Phases | Motor Voltage | Duty Cycle | Valve Operation | Valve Type | Power Source | Pump Control | Motor Electrical Specification | Relief Valve Adjustment Range (bar) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ZU4204BB-Q | 700 | For use with all Enerpac torque wrenches | 4000 | 4,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 115 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 115 V, 1 Ph, 50/60 Hz | 124 – 700 | 33 |
| ZU4204BB-QH | 700 | For use with all Enerpac torque wrenches | 4000 | 4,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 115 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 115 V, 1 Ph, 50/60 Hz | 124 – 700 | 37 |
| ZU4204BE-Q | 700 | For use with all Enerpac torque wrenches | 4000 | 4,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, European plug CE RF compliant | 124 – 700 | 34 |
| ZU4204TB-Q | 700 | For use with all Enerpac torque wrenches | 4000 | 4,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 115 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 115 V, 1 Ph, 50/60 Hz | 124 – 700 | 32 |
| ZU4204TE-Q | 700 | For use with all Enerpac torque wrenches | 4000 | 4,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, European plug CE RF compliant | 124 – 700 | 32 |
| ZU4204TI-Q | 700 | For use with all Enerpac torque wrenches | 4000 | 4,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, NEMA 6-15 plug | 124 – 700 | 32 |
| ZU4208BE-QH | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, European plug CE RF compliant | 124 – 700 | 38 |
| ZU4208BI-Q | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, NEMA 6-15 plug | 124 – 700 | 36 |
| ZU4208BI-QH | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, NEMA 6-15 plug | 124 – 700 | 40 |
| ZU4208TB-Q | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 115 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 115 V, 1 Ph, 50/60 Hz | 124 – 700 | 34 |
| ZU4208TE-Q | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, European plug CE RF compliant | 124 – 700 | 34 |
| ZU4208TI-Q | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 1,0 l/min | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, NEMA 6-15 plug | 124 – 700 | 34 |
| ZU4208TE-QR | 700 | For use with all Enerpac torque wrenches | 8000 | 8,0 | 11,5 | 8,8 | 1,2 | 1,0 | 1.7 | 50/60 Hz | 1 Ph | 208-240 V | Intermittent | Solenoid | 4-way, 2-position | Electric | Pendant | 208-240 V, 1 Ph, 50/60 Hz, European plug CE RF compliant | 124 – 700 | 48 |
