| Model Number | Maximum Operating Pressure (bar) | Capacity Class (tonnage) | Maximum Cylinder Capacity Retract (kN) | Stroke (mm) | Collapsed Height A (mm) | Extended Height B (mm) | Return Type | Plunger Type | Material | Cylinder Effective Area Retract (cm2) | Oil Capacity Retract (cm3) | Surface Treatment | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BRC25 | 700 | 2.5 | 24 | 127 | 264 | 391 | Single-Acting, Spring Return | Solid | Steel | 3,5 | 45 | Paint | 1,8 |
| BRC46 | 700 | 5 | 51 | 140 | 301 | 441 | Single-Acting, Spring Return | Solid | Steel | 7,3 | 101 | Paint | 4,5 |
| BRC106 | 700 | 10 | 105 | 151 | 289 | 440 | Single-Acting, Spring Return | Solid | Steel | 15,0 | 228 | Paint | 9,5 |
